MC4 FALG 12V compressor + Lubricator
Compressor for Fiamm air horn sirens
Separate 12v FIAMM Siren compressor. Suitable for, among others, the fire brigade sirens in the Netherlands.
Successor of FIAMM MC2/FALG
The MC4 compressor is part of the FIAMM MC4 System. A compact pneumatic air horn siren system for emergency vehicles without an on board air source.
For vehicles with an on board air source we advice the PS20 System
Delivery includes:
1x Compressor
1x Lubricator
| Productinformatie |
| Voltage |
12v |
| Amperage |
17a |
| Outgoing pressure in Bar |
1 Bar (14.5 Psi) |
| Fiamm Seriennummer |
921121 |
| Cycles per minute |
75 x |
| Operating Temperature |
-30°C to +60°C |
| Storage Temperature |
-30°C to +80°C |
| Corrosion Resistance |
> 96 hrs (Salt spray test) |
| Operating Humidity |
30 to 80 % |
| Maximum operarting time (with Lubricator) |
30 min. |
| Maximum operarting time (without Lubricator) |
10 min. |
| EU Registration |
10ECE |
| Weight Compressor |
1200 gr. |
| Weight Lubricator |
247 gr. |
| Application mainly for |
Fire Brigade Netherlands (Old) |
Pleaae note:
For this compressor you will need 12 Vdc power supply.
Product contains only the compressor and lubricator, not the trumpets.
