Home Pneumatic Fittings 12mm knee coupling

12mm knee coupling

2 x 12 mm knee coupling PTC

Product number

: CPL-955P-12

Current lead/delivery time

: 2-4 Work Days

€ 5,25

Price per unit

Quantity:

Order

Description
Information

Right angle connection piece for 12mm to 12mm tube.

With PTC connections for 12 mm and 12 mm tube.

The housing of this connecting piece is largely made of plastic.

With this connection piece you can connect 12mm hose to 12mm hose at a 90 degree angle.

This coupling can be used simply by pushing the tube into the ends of the coupling until it is firmly secured in place. The hose can be easily removed by pushing the ring back towards the coupling and pulling the tube out.

Abbreviations:

PTC: Push To Connect.
12mm hose: Outside diameter of the tube is 12 millimeters.

More information about hose sizes and threads can be found here: About threads

Shape

Angle

Tube size

12mm

Tube size (B)

12mm

Tube connection

PTC (Push To Connect)

Material

Synthetic / Plastic

Max pressure

15 bar

Made in

Germany
